We are always looking for more information on the Bach trombone mouthpiece line through the years. Our goal is to summarize all of the different marketing of these mouthpieces.
If you have any updated information, please contact us through the link in the header.
Bach Trombone Mouthpieces – Model Catalog
Catalog No. 341 Trombone
Catalog No. 350 Small Shank Tenor Trombone, Baritone & Euphonium Mouthpieces
Catalog No. K350 Mega Tone® Small Shank Tenor Trombone, Baritone & Euphonium Mouthpieces
Catalog No. K341 Mega Tone® Large Shank Tenor & Bass Trombone Mouthpieces
Model No. |
Depth of Cup |
Approx. Cup Dia. |
Rim Shape |
Throat | Back Bore | Description |
1G | Deep | 28.00 mm | Medium thin, well rounded. | .319″ | 800S | Extra large and Deep for extraordinary power and depth of tone. Among the largest and most powerful bass trombone mouthpieces produced today. |
1 1/4G | Deep | 27.50 mm | Medium thin, well rounded. | .276″ | 429 | Cup diameter is smaller than No. 1G, but still very large and Deep, with the sonority preferred by the modern American school. |
1 1/4GM | Deep | 27.50 mm | Medium thin, well rounded. | .319″ | 800S | Same rim and cup as No. 1 1/4G, but with a larger throat and backbore for large, powerful sound, well in tune. |
1 1/2G | Deep | 27.00 mm | Medium wide, well rounded. | .276″ | 429 | A large mouthpiece with powerful tone in the low register and great carrying power. For many years, the standard mouthpiece for the serious bass trombone player. |
1 1/2GM | Deep | 27.00 mm | Medium wide, well rounded. | .319″ | 800S | Larger throat and backbore than the No. 1 1/2G results in less resistance, larger dynamic range, Deeper, warmer sound. |
2G | Deep | 26.75 mm | Medium narrow. | .276″ | 429 | Deep, full, resonant tone. Big low register even through the pedal tones. |
3G | Deep | 26.26 mm | Medium wide, well rounded. | .276″ | 429 | Same rim shape and diameter as No. 3 small shank tenor trombone, but with a Deep bass trombone cup, throat, and backbore to facilitate pedal tones.Same cup diameter and rim as the No. 3 tenor trombone mouthpiece, but with a deep bass trombone cup. Full, vibrant bass trombone tone of rich, dark timbre. Ideal for 3rd trombonist in symphonic band or symphony orchestra. Facilitates pedal tones. (1954) |
4G | Deep | 26.00 mm | Medium wide, slightly rounded. | .276″ | 429 | Same rim shape and diameter as No. 4 small shank tenor trombone. A versatile, large diameter mouthpiece especially useful when only one trombone is used for both the upper and very low register. |
4GB | Deep | 26.00 mm | Medium thin, very well rounded. | .276″ | 429 | Same cup, throat and backbore as the No. 4G with a more rounded rim. |
5G | Deep | 25.50 mm | Medium wide, semi-flat. | .276″ | 429 | Same rim shape and diameter as No. 5 small shank tenor trombone. Similar playing characteristics to No. 4G with a slightly smaller cup diameter. |
5GL | Medium Deep | 25.50 mm | Medium wide, semi-flat. | .276″ | 429 | Old style, shallower model than No. 5G, facilitates upper range. |
5GB | Deep | 25.50 mm | Medium thin, very well rounded. | .276″ | 429 | Same cup, throat and backbore as the No. 5G with a more rounded rim. |
5GS | Medium Deep | 25.50 mm | Medium wide, semi-flat. | .261″ “G” |
420 (modified) |
Shallower “G”-style cup with smaller throat and backbore than No. 5G produces easy high register, slightly brighter sound. |
6 1/2A | Medium Deep | 25.40 mm | Medium wide, well rounded. | .276″ | 429 | Same rim and cup as No. 6 1/2A small shank tenor trombone, but with full bass trombone throat and backbore for a rich, compact sound of large volume. |
6 1/2AL | Medium Deep | 25.40 mm | Medium wide, well rounded. | .261″ “G” |
420 | The same cup, throat, and backbore as No. 6 1/2AL small shank tenor trombone but with bass shank. It requires a well developed embouchure. |
6 1/2AM | Medium Deep | 25.40 mm | Medium wide, well rounded. | .257″ “F” |
413 | The same rim, cup, throat, and backbore as No. 6 1/2AM small shank tenor trombone mouthpiece, but with bass shank. |
Catalog No. 350 Small Shank Tenor Trombone, Baritone & Euphonium Mouthpieces | ||||||
3 | Medium deep | 26.26 mm | Medium wide, well rounded. | Extra-large cup for players with a robust embouchure. | ||
4 | Medium | 26.00 mm | Medium wide, well rounded. | Very large cup; principally used by players having healthy, strong embouchures. | ||
4C | Medium shallow | 25.75 mm | Medium wide, well rounded. | Large cup with a brilliant tone. Requires a powerful, natural embouchure. | ||
5 | Medium | 25.50 mm | Medium wide, semi-flat. | For players with good, natural embouchures. Rather large cup. Produces a full, mellow, sonorous tone. |
||
5G | Deep | 25.50 mm | Medium wide, semi-flat. | Same as No. 350-5 except for .276″ throat and #429 backbore (same as No. 341-5G but with small shank). | ||
5GB | Deep | 25.50 mm | Medium thin, very well rounded. | Same as No. 350-5 except for thin rim (same as No. 341-5G but with small shank). | ||
5GS | Medium | 25.50 mm | Medium wide, semi-flat. | Same as No. 5 but with larger “G” throat and #420 backbore. | ||
6 | Medium | 25.50 mm | Medium wide, well rounded. | Fairly large cup. For players with a strong embouchure. Full, solid, mellow tone. | ||
6 1/2A | Medium deep | 25.40 mm | Medium wide, well rounded. | Slightly larger than medium with standard-size throat and backbore. Rich, compact tone of large volume. | ||
6 1/2AL | Medium deep | 25.40 mm | Medium wide, well rounded. | The same rim and cup as No. 6 1/2A, but with a larger “G” throat and #420 backbore for trombonists who strive for a Teutonic tone quality. Recommended for euphonium players who desire a round, mellow tone of great carrying power and substantial volume. | ||
6 1/2AM | Medium deep | 25.40 mm | Medium wide, well rounded. | Symphonic model tenor trombone mouthpiece features the same cup and rim as No. 6 1/2A, but with symphonic “F” throat and #413 backbore. | ||
6 3/4C | Medium shallow | 25.00 mm | Medium wide, well rounded. | Produces a full, clear, rather brilliant timbre. For trombonists with good, well-trained embouchures. | ||
7 | Medium | 24.75 mm | Medium wide, not too sharp. | The ideal mouthpiece for the artist desiring a beautiful, ringing tone with sufficient volume for melody playing. | ||
7C | Medium shallow | 24.75 mm | Medium wide, not too sharp. | Designed for players who prefer a medium-large cup to assure a large volume of tone. The rather shallow cup produces great brilliancy. | ||
8 | Medium | 24.75 mm | Slightly wide and flat. | Corresponds in cup design with No. 7, but with a wider rim. Players with heavier lips prefer this model. |
||
8 1/2BW | Medium shallow | 24.75 mm | Very wide, well rounded. | For players with heavy lips who need support to prevent the rim from digging. Well liked by musicians who do strenuous work. Produces lively, brilliant tone with easy high register. |
||
9 | Medium deep | 24.72 mm | Medium wide. | Possesses a beautiful, rich, rather mellow timbre. | ||
11 | Medium deep | 24.70 mm | Medium wide. | Same style as No. 9 but slightly smaller. Produces a magnificent round tone of great carrying power. An excellent model for euphonium and baritone players. | ||
11C | Medium shallow | 24.70 mm | Medium wide. | Same size as No. 11 but with a medium shallow cup for a brilliant ringing tone of large volume. | ||
12 | Medium | 24.50 mm | Medium wide. | An excellent all-around mouthpiece. Combines a fine, solid, dark tone, excellent flexibility, great volume and easy response. | ||
12C | Medium | 24.50 mm | Medium wide. | Same size and rim as No. 12 but with a more brilliant, crisp tone. The best selling model for all-around playing. | ||
12E | Very shallow | 24.50 mm | Medium wide. | This model, designed principally for Eb alto trombone, can be used on Bb trombone or bass trumpet when a brilliant, brassy tone is desirable. Also recommended for use in the extreme high register. | ||
14D | Shallow | 24.50 mm | Medium wide. | Well suited for playing in the high register. Very effective for coloratura work. | ||
14 1/2D | Shallow | 24.50 mm | Medium wide. | Small, shallow cup and wider rim aid the high register while producing a clear, lively tone. | ||
15 | Medium deep | 24.40 mm | Medium wide. | A full-toned mouthpiece of mellow timbre. | ||
15C | Medium shallow | 24.40 mm | Medium wide. | Medium shallow cup produces a clear, lively tone. Players with thin lips or weak embouchures will find it helpful. | ||
15CW | Medium shallow | 24.40 mm | Very wide, well rounded. | Designed for great brilliancy and resistance to facilitate the very high tones. The wide cushion rim distributes pressure—an advantage to players with soft, fleshy lips. | ||
15D | Shallow | 24.40 mm | Medium wide. | Has a rim similar to No. 15C but the shallower cup produces a clear, crisp tone, effective in the extreme high register. | ||
15E | Very shallow | 24.40 mm | Medium wide. | Designed for Eb alto trombone but used also by players who continually play in the extreme high register. Also used for bass trumpet where a martial tone quality is desired. | ||
15EW | Very shallow | 24.30 mm | Extra wide cushion, well rounded. | The choice of artists who play in the extreme high register for long hours. Produces a brilliant, piercing tone. | ||
Catalog No. K350 Mega Tone® Small Shank Tenor Trombone, Baritone & Euphonium Mouthpieces | ||||||
4 | Medium | 26.00 mm | Medium wide, well rounded. | Very large cup; principally used by players having healthy, strong embouchures. | ||
5 | Medium | 25.50 mm | Medium wide, semi-flat. | For players with good, natural embouchures. Rather large cup. Produces a full, mellow, sonorous tone. | ||
5GS | Medium | 25.50 mm | Medium wide, semi-flat. | Same as No. 5, but with larger “G” (1 7/64″) throat and #420 backbore. | ||
6 1/2A | Medium Deep | 25.40 mm | Medium wide, well rounded. | Slightly larger than medium with standard size throat and backbore. Rich, compact tone of large volume. | ||
6 1/2AL | Medium Deep |
25.40 mm | Medium wide, well rounded. | The same rim and cup as No. 6 1/2A, but with “G” (1 7/64″) throat and #420 backbore, for trombonists who strive for a Teutonic tone quality. | ||
6 1/2AM | Medium Deep | 25.40 mm | Medium wide, well rounded. | Symphonic model tenor trombone mouthpiece features the same cup and rim as No. 6 1/2A, but with symphonic throat and backbore. | ||
7C | Medium shallow | 24.75 mm | Medium wide, not too sharp. | For players who prefer a medium-large cup to assure a large volume of tone. Rather shallow cup produces great brilliancy. | ||
11C | Medium shallow | 24.70 mm | Medium wide. | Medium shallow cup produces a brilliant ringing tone of large volume. | ||
Catalog No. K341 Mega Tone® Large Shank Tenor & Bass Trombone Mouthpieces | ||||||
1G | Deep | 28.00 mm | Medium thin, well rounded. | .319″ | 800S | Extra large and Deep for extraordinary power and depth of tone. Among the largest and most powerful bass trombone mouthpieces produced today. |
1 1/4GM | Deep | 27.50 mm | Medium thin, well rounded. | .302″ “N” |
800S | Same rim and cup as No. 1 1/4G, but with a larger throat and backbore for a large, powerful sound, well in tune. |
1 1/2G | Deep | 27.00 mm | Medium wide, well rounded. | .277″ “J” |
429 | A large mouthpiece with a powerful tone in the low register and great carrying power. For many years, the standard mouthpiece for the serious bass trombone player. |
1 1/2GM | Deep | 27.00 mm | Medium wide, well rounded. | .302″ “N” |
800S | Larger throat and backbore than No. 1 1/2G results in less resistance, larger dynamic range, Deeper, warmer sound. |
4G | Deep | 26.00 mm | Medium wide, slightly rounded. | .277″ | 429 | Same rim shape and diameter as No. 4 small shank tenor trombone. Versatile, large diameter mouthpiece especially useful when only one trombone is used for both the upper and very low register. |
5G | Deep | 25.50 mm | Medium wide, semi-flat. | .277″ “J” |
429 | Same rim shape and diameter as No. 5 small shank tenor trombone. Fairly large and Deep, with a dark, mellow tone, favoring the low register. |
5GS | Medium | 25.50 mm | Medium wide, semi flat. | .265″ 17/64″ |
420 | Same rim and cup as No. 5G but with 17/64″ throat and #420 backbore. |
6 1/2A | Medium Deep | 25.40 mm | Medium wide, well rounded. | .277″ | 429 | Same rim and cup as No. 6 1/2A small shank tenor trombone, but with a full bass trombone throat and backbore for a rich, compact sound of large volume. |
6 1/2AL | Medium Deep | 25.40 mm | Medium wide, well rounded. | .265″ 1 7/64″ |
420 | Same specifications as No. 6 1/2AL small shank tenor trombone but with .265″ throat. Requires well-developed embouchure. |
Sources:
© Conn Selmer, Inc.
